Microsoft Surface Pro 4 Compatibility with EIZO Monitors
[Items of validation]
- Displays BIOS image correctly
- Displays the image correctly with the recommended resolution and refresh rate
- Plug & Play works correctly
- Colors of the image are correct
- Noise and blinking does not occur
- "Standby", "Sleep" "Restart" and "Shutdown" functions work correctly
- USB hub works correctly (Excludes EV3285, EV2785 and EV2780)
- Speakers work correctly (FlexScan only)
- ColorNavigator works correctly (ColorEdge only)
- This information is provided based on our in-house testing and we do not guarantee the compatibility in respective user environments.
- The latest firmware version 2.7.136.0. has been applied using Microsoft Surface Dock Updater.
| PC | Surface Pro 4 | ||
|---|---|---|---|
| Docking Station | － | Surface Dock | |
| CPU | Intel Core i5-6300U CPU@2.4GHz 2.5GHz | ||
| OS | Name | Windows 10 Pro 64-bit | |
| Version | 1709 | ||
| OS Build | 16299.125 | ||
| GPU | Intel HD Graphics 520 | ||
| GPU Driver Ver. | 21.20.16.4627 | ||
| Connector | Mini DisplayPort | ||
| Cable | PM200 (Mini DisplayPort - DisplayPort） | ||
| FlexScan | EV3285 | Yes | Limited *1 |
| EV3237 | Yes | Limited *1 | |
| EV2785 | Yes | Limited *1 | |
| EV2780 | Yes | Limited *1 | |
| EV2750 | Yes | Limited *1 | |
| EV2730Q | Yes | Yes | |
| EV2456 | Yes | Yes | |
| EV2451 | Yes | Yes | |
| EV2450 | Yes | Yes | |
| ColorEdge | CG318-4K | Yes | Yes |
| CG248-4K | Yes | Yes | |
| CG277 | Yes | Yes | |
| CG2730 | Yes | Limited *2 | |
| CG247X | Yes | Yes | |
| CG2420 | Yes | Yes | |
| CS2730 | Yes | Limited *2 | |
| CS2420 | Yes | Yes | |
| CS230 | Yes | Yes | |
When using Surface Dock, Surface Pro 4 may blackouts or may not enter the power save mode.
*1 The monitor does not enter the power save mode.
*2 By turning on / off the monitor's main switch or plug in / out the monitor cable, the monitor may enter the power save mode. (Repeat the action to redisplay the screen.)
