Compatibility

compatibility


We have tested the 4K resolution compatibility between ColorEdge 4K monitors and SDI converters for use in professional video creation.



Output / Input Manufacturer Product Monitor
CG3145 CG319X CG318-4K CG248-4K CS2740
SDI-HDMI AJA Hi5-4K-Plus Yes
(recommended)
Yes
(recommended)
Yes
(recommended)
Yes
(recommended)
Yes
(recommended)
Hi5-4K Not Tested Not Tested Yes Not Tested Not Tested
Blackmagic Design Teranex Mini SDI to HDMI 12G Yes Yes Yes Yes Not Tested
SDI-DisplayPort APANTAC Micro-4K-DP 1 Not Supported Not Supported Yes 2 Yes 2 Not Tested
Blackmagic Design Teranex Mini SDI to DisplayPort 8K Yes 3,4,5 Yes 3,4,5 Not Tested Not Tested Yes 3,4,5

1 Applicable for Micro-4K-DP serial number 170518001 or later.

2 YUV signal is converted to RGB signal. Does not operate with RGB signal input.

3 YUV signal is converted to RGB signal.

4 The range of the input signal is extended from Limited to Full for display.

5 The resolution information is displayed monitor native resolution.







4K Monitor Compatibility with Video Devices

For compatibility between ColorEdge 4K monitors and video devices, click here.



FAQs

Q: Do CG3145, CG319X , CG279X and CS2740 support SDI input?

A: No. Please refer to the above list for compatible converters.



Q: Which monitors support HDR10?

A: CG3146, CG3145, CG319X, and CG279X can display signal from an HDR10 output device. Please refer to the setup manual to select the appropriate gamma and color space for HDR10.



Q: Do other HDR CG Series monitors support HDR10?

A: No. Models other than those listed above do not support HDR10.



Implementing 4K Monitors

Get information on EIZO 4K monitors such as compatibility with other devices and more.
